Silicone Keyboard Single Panel Toys Making Machine Module Membrane Switch
1.Customizability: The Deson Custom Logo Silicone Keyboard Single Panel Toys Making Machine Module Silicone Key Membrane Switch allows for innovative design flexibility as it can be customized in terms of shape, size, and logo, catering to individual brand uniqueness and preferences.
2.Durable: The product is made with high-quality silicone material, providing resilience and long-lasting performance, while also ensuring protection against wear and tear, making it ideal for various home appliance applications.
3.Advanced Back Adhesive: With options such as 3M9498A/3M467/3M468/3M200 for the back adhesive, the silicone membrane switch offers a secure and reliable attachment to various surfaces, ensuring its stable functionality in different environments.
4.ISO Certified: The silicone keyboard is certified by ISO14001:2015 and ISO9001:2015 standards, demonstrating Deson's commitment to providing eco-friendly and high-quality products for the manufacturing industry.
5.Competitive MOQ: By requiring a minimum order quantity of 100pcs, Deson maintains a balance between providing economies of scale to larger customers while still catering to smaller clients and niche markets.
Model:DIY
Send Inquiry
Product Description
Electrical Characteristics:
Circuit Rating: 35V (DC), 100mA, 1W
Contact Resistance: 10Ω–500Ω (varies with lead length and material)
Insulation Resistance: 100MΩ at 100V
Dielectric Withstanding Voltage: 250V Rms (50–60Hz, 1 minute), no breakdown or arcing observed after testing
Contact Bounce Time: ≤5ms
Operating Life: Planar type ≥5,000,000 cycles; Tactile type ≥1,000,000 cycles
Mechanical Characteristics:
Actuation Force: Planar type 57–284g (2–10oz); Tactile type 170–397g (6–14oz)
Switch Travel: Planar type 0.1–0.5mm; Tactile type 0.6–1.5mm
Environmental Parameters:
Operating Temperature: Planar type (including dome) –20°C to +80°C; Dome type –20°C to +60°C
Storage Temperature: Planar type (including dome) –40°C to +80°C; Dome type –40°C to +60°C
Humidity: 40°C, 90%–95%, 240 hours
