Circuit Rating: 35V (DC), 100mA, 1W
Contact Resistance: 10Ω~500Ω (varies according to the length and material of the lead wires)
Insulation Resistance: 100MΩ 100V
Dielectric Withstanding Voltage: 250V Rms (50-60Hz 1min) No breakdown or arcing after test
Contact Bounce Time: ≤5ms
Operating Life: Flat Type ≥5 million cycles
Tactile Type: ≥1 million cycles
Mechanical Characteristics:
Operating Force: Flat Type 57~284g (2~10oz)
Tactile Type: 170~397g (6~14oz)
Switch Travel: Flat Type 0.1~0.5mm
Tactile Type: 0.6~1.5mm
Environmental Specifications:
Operating Temperature: Flat Type (including spring plate) -20℃~+80℃
Embossed Type: -20℃~+60℃
Storage Temperature: Flat Type (including spring plate) -40℃~+80℃
Embossed Type: -40℃~+60℃
Humidity: 40℃, 90%~95%, 240 hours
